Vertical seat with set screwsWith outer spherical ball bearing(UCP2)_product center-Maieken (Shanghai) Bearing Co., LTD

UCP2

Product Parameter

PDF download	Shaft Dia.		Dimensions(mm)(inch)										Unit No.	Bolt Used (mm) (in.)	Bearing No.	Housing No.	Weight(kg)(lb)
PDF download	d (in.)	d (mm)	H	L	J	A	N	N1	H1	H2	S	B	Unit No.	Bolt Used (mm) (in.)	Bearing No.	Housing No.	Weight(kg)(lb)
	21/2	-	4.0000	12.874	10.315	3.4646	1.0630	1.4173	1.2992	7.8740	1.5630	3.7795	UCP218-56	7/8	UC218-56	-	29.6
	-	90	101.6	327	262	88	27	36	33	200	39.7	96.0	UCP218	M22	UC218	P218	13.45
	23/4	-	3.7480	12.205	9.7244	3.2677	0.9842	1.1811	1.2598	7.3622	1.3425	3.3740	UCP217-52	3/4	UC217-52	-	24.8
	-	85	95.2	310	247	83	25	30	32	187	34.1	85.7	UCP217	M20	UC217	P217	11.28
	-	-	3.5000	11.496	9.1338	3.0709	0.9842	1.1811	1.1811	6.8898	1.3110	3.2520	UCP216-50	3/4	UC216-50	-	19.9
	-	80	88.9	292	232	78	25	30	30	175	33.3	82.6	UCP216	M20	UC216	P216	9.03
	3	-	3.2520	10.827	8.5433	2.9134	0.9842	1.1811	1.1024	6.4173	1.3110	3.0630	UCP215-48	3/4	UC215-48	-	16.5
	-	75	82.6	275	217	74	25	30	28	163	33.3	77.8	UCP215	M20	UC215	P215	7.62
	23/4	-	3.1260	10.472	8.2677	2.8346	0.9842	1.1811	1.0630	6.1811	1.1890	2.9370	UCP214-44	3/4	UC214-44	-	15.2
	-	70	79.4	266	210	72	25	30	27	157	30.2	74.6	UCP214	M20	UC214	P214	6.90
